the setting.
3. If resetting is required, press the Setting button to
return to the System Setting interface, then enter
Time Setting interface, and repeat the above steps.
4. Press the Home button to return to the Home inter-
face, and power off the machine as needed.
Machine Information
1. On the System Setting interface, select the “Ma-
chine Info” by pressing the up shift key and down
shift key, and press the OK button to enter the Ma-
chine Information interface.
Fig 16 Machine Information interface
2. This interface is mainly used to query the detailed
information of the current software program version
of the machine and to clear the current working
time.
3. Select the “Clear” option, press and hold the OK
button for 3 seconds to complete the clearing of cur-
rent working time.
4. Press the Home button to return to the Home inter-
face, and power off the machine as needed.
Language Setting
1. On the Home interface, press the Setting button to
enter the System Setting interface.
Fig 17 System Setting interface
2. Change the selected item by pressing the up shift
key, down shift key, left shift key and right shift key,
and press the OK button to complete language
setting.
Unit Setting
1. On the Home interface, press the Setting button to
enter the System Setting interface.
Fig 18 System Setting interface
2. Change the selected item by pressing the up shift
key, down shift key, left shift key and right shift key,
and press the OK button to complete unit setting.
