ELECTRICAL SYSTEM
Table 8-4 Machine fault codes description (Continued)
56
Main boom relative
angle sensor fault
Main boom relative angle
sensor fault
Check the wiring of main boom relative angle
sensor
57
Low battery level
alarm
Low battery level alarm Check whether the battery voltage is too low
58
Front right steer
sensor fault
Front right steer sensor fault Check the wiring of front right steer sensor
59 Clutch fault Clutch fault
Check whether the clutch can be properly
engaged or the sensor is correctly wired.
60 Low fuel level fault Low fuel level fault
Check whether the fuel level is too low or the
sensor is correctly wired.
Motor Controller Fault Codes
Table 8-5 General fault codes of motor controller
Fault
code
Description
Cause Solution
0012
Overcurrent of pump motor
1. Encoder fault or circuit
interference;
2. Motor UVW short-
circuited;
3. Mismatched motor
parameters;
4. Controller fault.
1. Check the encoder surface for stains, re-
place it if necessary;
2. Check the motor UVW 3-phase cable for
short circuit or damage, and check the
controller UVW 3-phase cable for damage
using a multimeter;
3. Monitor the controller current when fully
loaded, re-match the motor if necessary;
4. If no problem is found in the above inspec-
tions, replace the controller.
0112
Overcurrent of FL motor
controller
0212
Overcurrent of FR motor
controller
0312
Overcurrent of RL motor
controller
0412
Overcurrent of RR motor
controller
0013
Current sensor fault of pump
motor controller
1. Motor UVW short-
circuited;
2. Current sensor of the
controller faulted.
1. Check the UVW 3-phase cable for short
circuit or current leakage;
2. If no problem is found in the above inspec-
tions, replace the controller.
0113
Current sensor fault of FL
motor controller
0213
Current sensor fault of FR
motor controller
0313
Current sensor fault of RL
motor controller
0413
Current sensor fault of RR
motor controller
0014
Pre-charging fault of pump
motor controller
1. Voltage drop due to
loads connected to B+
circuit;
2. Controller damaged.
1. Check whether other high-power loads are
connected to the controller B+ circuit;
2. Check the KSI wiring, and measure the
voltage using a multimeter to check for
abnormality;
3. If no problem is found in the above inspec-
tions, replace the controller.
0114
Pre-charging fault of FL
motor controller
0214
Pre-charging fault of FR
motor controller
0314
Pre-charging fault of RL
motor controller
0414
Pre-charging fault of RR
motor controller
