AB16EJ Plus Operation Manual
19
© March 2023
4 TECHNICAL PARAMETERS
4.1 MACHINE SPECIFICATIONS
Table 4-1 Specifications
ITEM
Metric Imperial
Product Category
Power type Battery
Axle type Oscillating axle
DIMENSION
Max. platform height
15.8 m 51 ft 10 in
Max. working height
17.8 m 58 ft 5 in
Max. horizontal reach
(250 kg/340 kg/454 kg)
9 m/8.1 m/7 m 29 ft 6 in/26 ft 7 in/23 ft
Max. horizontal working envelope
(250 kg/340 kg/454 kg)
9.6 m/8.7 m/7.6 m 31 ft 6 in/28 ft 7 in/24 ft 11 in
Overall length (stowed)
7.6 m 24 ft 11 in
Overall length (transport)
6.1 m 20 ft
Overall width (stowed)
2.3 m 7 ft 7 in
Overall width (transport)
2.3 m
7 ft 7 in
Overall height (stowed)
2.25 m 7 ft 5 in
Overall height (transport)
3.1 m 10 ft 2 in
Wheelbase 2.3 m 7 ft 7 in
Ground clearance 0.37 m 1 ft 3 in
Max. up and over height
7.9 m 25 ft 11 in
Platform dimensions (L×W×H)
Options
1.45×0.85×1.1 m
1.83×0.85×1.1 m
Options
4 ft 9 in×2 ft 9 in×3 ft 7 in
6 ft×2 ft 9 in×3 ft 7 in
PERFORMANCE
Rated platform capacity
250 kg (unrestricted)/340 kg
(restricted)/454 kg (restricted)
551 lb (unrestricted)/750 lb
(restricted)/1000 lb (restricted)
Max. number of people on the
platform (restricted/unrestricted)
3 persons/2 persons
Drive speed (stowed)
0～5.5 km/h
0～3.4 mph
Drive speed (raised)
0～1.1 km/h
0～0.68 mph
Gradeability (4WD)
40%
Turntable slewing (angle/continuity)
355°/non-continuous
Platform rotation angle
180°
