5 PRE-OPERATION INSPECTION
A pre-operation check must be performed before each
operation, before resuming operations, and before
changing operators, as well as after each repair. Please
carefully check each item according to the content of
this section.
5.1 MACHINE COMPONENTS
Fig 1 Machine components
Table 5-1
1. Platform
7. Upper articulated boom
13. Rear wheel (non-steering wheel)
2. Foot switch 8. Lower articulated boom 14. Hydraulic tank
3. Platform Controls 9. Front wheel (steering wheel)
15. Harness anchorage point
4. Jib (if equipped) 10. Ground controls 16. Auxiliary power unit (APU)
5. Telescopic boom 11. Battery compartment
6. Main boom 12. Power switch
