OPERATION INSTRUCTIONS
AB16EJ Plus Operation Manual
41
© March 2023
breakers on the supply side shall be as follows:
Input voltage Rated power
110VAC (210VAC)
≥3 kW
220 VAC (380 VAC)
≥6 kW
• Please refer to the following table to determine the
appropriate wire diameter and length of the charging
cable;
Voltage parameters
Wire diameter
Cable length
220 VAC-3 kW
110 VAC-1.5 kW
2.5 mm² ≤10 m
380 VAC-6 kW
210 VAC-3 kW
4 mm² 10 m ≤ L ≤ 100 m
Charging Display
1. Once the charger is connected to mains supply the
LED light will flash, and the default code for the
charging curve will be displayed.
2. Once the curve code is displayed the charger will
enter the charging mode.
3. In charging mode, the charging indicator illuminates
in different modes based on the charging progress.
• With a battery level of less than 50% the 50% in-
dicator flashes at low frequency;
• With the battery level between 50% and 75% the
75% indicator flashes at high frequency;
• With the battery level between 75% and 100%,
the 100% indicator illuminates steadily;
• In case of a battery failure the battery fault indi-
cator illuminates steadily.
7.6 TURNTABLE SLEWING
Before slewing the turntable, make sure that the
boom has sufficient distance from surrounding
walls, obstacles, etc.
Perform operation from the ground:
1. Rotate the turntable clockwise: Move and hold the
enable switch, and push the turntable slewing
switch downwards, the turntable will rotate
clockwise.
2. Rotate the turntable counterclockwise: Move and
hold the enable switch, and push the turntable slew-
ing switch upwards, the turntable will rotate
counterclockwise.
Perform operation from the platform:
1. Rotate the turntable clockwise: Depress the foot
switch, push the main boom luffing/turntable slewing
control handle to the left, the turntable will rotate
clockwise.
2. Rotate the turntable counterclockwise: Depress the
foot switch, push the main boom luffing/turntable
slewing control handle to the right, the turntable will
rotate counterclockwise.
Note: When performing the operation from the platform,
the rotation speed of the turntable is in direct proportion
to the travel distance of the control handle. The shorter
the travel distance, the slower the speed.
7.7 TRAVELING
• The machine cannot travel with the boom
positioned higher than the horizontal unless it
is on a solid and flat surface without exceeding
the maximum gradeability.
• The machine must not be driven on slopes,
steps or arched surfaces that exceed the maxi-
mum gradeability of the machine.
• Before traveling, confirm the traveling control
direction, and make sure the boom is above
the rear-wheel drive axle. If the boom is above
the front-wheel axle, the traveling and steering
control directions will be opposite to the indi-
cated directions.
• Extreme care must be taken when driving the
machine in reverse or with the platform raised.
• When driving the machine in potentially dan-
gerous situations such as driving on slopes or
reversing, operate the handle in small incre-
ments to avoid danger due to excessive speed.
