TECHNICAL PARAMETERS
AB16EJ Plus Operation Manual 21
© March 2023
Table 4-1 Specifications(Continued)
ITEM
Metric Imperial
Storage environment
Store at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment with
90% relative humidity (max.) (20℃ [68℉]), protected from rain, sun,
corrosive gas, flammable or explosive materials.
Note:
a) The platform height plus the operator height (assumed to be 2 m [6 ft 7 in]) equals the working height.
b) The maximum horizontal reach plus the arm length of the operator (assumed to be 0.6 m [1 ft 11 in]) is the
maximum horizontal working envelope.
c) The ground bearing data is approximate, without considering different options, thus it is applicable only when
taking an adequate safety factor into account.
d) Different regions should use hydraulic oil, engine oil, coolant, fuel, lubricating oil, etc., that are suitable for the
environmental temperature requirements.
e) In cold weather, auxiliary devices are needed to start the machine.
f) Rated platform load capacity refers to the maximum allowable load on the platform, including the weight of
persons, materials, tools, accessories and other objects.
g) Lead-acid batteries are not recommended for use in environments below 0°C, as such usage will cause rapid
decay in battery life, affecting the machine's endurance.
4.2 MOVEMENT SPEED
Table 4-2
ITEM TIME
Raise main boom 33 - 39 s
Lower main boom 29 - 35 s
Raise articulated boom 41 - 49 s
Lower articulated boom 32 - 38 s
Rotate the turntable (355°)
90 - 100 s
Extend the main boom 32 - 38 s
Retract the main boom 22 - 27 s
Rotate the platform (180°)
18～22 s
Level platform upward
45 - 55 s
Level platform downward
35 - 45 s
Raise jib
32 - 38 s
Lower jib
22 - 28 s
Max drive speed (30 m [98.4 ft])
-stowed
18～22 s
Max drive speed (30 m [98.4 ft])
-operating
89 - 109 s
Table 4-2 (Continued)
ITEM TIME
Braking distance at maximum drive
speed
S ≤ 2 m (6.6 ft)
a) The function speed depends on the start and end
point of the movement rather than the controls/
switches.
b) The drive speed test results will vary with tires of
different specifications.
c) All speed tests should be conducted from the
platform controller. Test results will differ if tested
from the ground controller.
d) All tests should be conducted with the hydraulic oil
temperature higher than 50 - 60 ℃ (122 - 140 ℉). If
the hydraulic oil temperature is too low the test
results will be affected.
Test requirements:
Raise/lower main boom : For this test, the articulated
boom must be fully lowered, the telescopic boom must
be fully retracted. Raise the main boom from the lowest
to the highest position, and lower it again from the high-
est to the lowest position. Perform these maneuvers for
two times.
Raise/lower articulated boom : Raise the articulated
boom from the lowest to the highest position, and lower
it again from the highest to the lowest position. Perform
these maneuvers for two times.
Rotate turntable : With the boom stowed, rotate the
turntable through two full cycles.
