© March 2023 22 AB16EJ Plus Operation Manual
TECHNICAL PARAMETERS
Extend/retract main boom : With the main boom hori-
zontally positioned, extend the main boom from the fully
retracted to the fully extended position, and retract it
from the fully extended to the fully retracted position
again. Perform this maneuver for two times.
Rotate platform : With the platform horizontal, rotate
the platform from the full left to the full right position, and
rotate it again from the full right to the full left position.
Perform this maneuver for two times.
Level the platform ： Level the platform upward from
the lowest to the highest position, and level the platform
downward from the highest to the lowest position. Per-
form this maneuver for two times.
Raise/lower the jib : With the platform horizontal, raise
the jib from the lowest to the highest position, and lower
the jib again from the highest to the lowest position. Per-
form this maneuver for two times.
Drive, stowed position : With the machine on a level
surface, switch to the high gear, and push the drive con-
trol handle to maximum travel distance to drive forward
and reverse for 30 m/98.4 ft respectively for two times.
Drive, operating position : With the machine on a level
surface, push the drive control handle to maximum trav-
el distance to drive forward and reverse for 30 m/98.4 ft
respectively for two times.
Braking distance : With the machine on a level surface,
once the machine reaches the maximum drive speed,
immediately release the control handle (start timing) un-
til the machine stops; drive forward and reverse for
30 m/98.4 ft respectively for two times.
