OPTIONS
AB16EJ Plus Operation Manual
75
© March 2023
Instructions for use
Tipping Hazard
• Do not use the glass panel sup-
port in wind speeds exceeding
12.5 m/s (28 mph).
• The glass panel support and its
load will affect the load capacity
of the platform; this must be fac-
tored into the total platform
capacity.
• In case of excessive combined
weight of the glass panel support
and its load, the maximum num-
ber of people on the platform
should be reduced.
• The glass panel surface area will
expose the machine to an in-
creased wind load and reduce the
stability of the machine.
• Only use the glass panel support
with the machine on flat, solid
ground.
Table 11-6
Glass panel support capacity 115kg (253.5lbs)
Weight of the glass panel
support
15.2 kg (33.5 lbs)
Maximum allowable wind
speed
12.5 m/s (28 mph)
Maximum allowable glass
panel surface area
0.17 m²
(1.83 sq.ft)
Maximum allowable vertical
height of glass panel
1.2 m (3 ft 11 in)
1. Ensure that the glass panel support is installed cor-
rectly and secured to the platform.
2. Place the load upon the glass panel support, and
ensure that the load remains parallel with the longi-
tudinal axis of the glass panel support.
3. Ensure the load is centered on the same vertical
plane with the center of the glass panel support.
4. Use the straps to secure the load to the platform.
5. Gently push and pull on the load to ensure that the
load is safely secured.
6. When the machine is operating, ensure that the load
is always secured in place.
NOTICE
Ensure that the load remains at a proper distance
from the gate bar to prevent abrasion, crush or other
damage to the load.
11.4 PLATFORM MESH
The platform mesh comes in two types: half and full
height mesh; it can effectively prevent tools or other ma-
terials from dropping off the platform.
Unsafe Operation Hazard
• The platform mesh may only be
installed on designated models
and the corresponding markets,
not on other models or in other
markets.
• Before using the platform mesh,
the safety rules and all operating
instructions should be read,
understood and observed. This
manual should always be kept as
an integral part with the platform
mesh.
Installation and Removal
Unsafe Operation Hazard
• The platform mesh may only be
installed on designated models
and the corresponding markets,
not on other models or in other
markets.
• The platform mesh may only be
installed on platforms equipped
with a swing gate.
Installation instructions
1. Install the swing gate frame.
To Next Page
