© March 2023 28 AB16EJ Plus Operation Manual
CONTROLLERS AND INDICATORS
Table 6-1 (Continued)
No. Indication
Description
platform controls are not active.
With the switch turned to the platform control position (right)
functions can only be activated from the platform controller,
the ground controls are not active.
6 Enable switch
Move and hold the switch – all functions will be enabled to
operate.
7
Auxiliary power switch
Provides auxiliary (emergency) power in case of main power
source failure.
8
Articulated boom luffing switch Controls luffing movements of the articulated boom
9
Turntable slewing switch
Controls turntable rotation
10
Main boom telescoping switch Controls main boom telescoping
11 Horn Press the button for the horn to sound.
12 Platform rotate switch
Controls platform rotation
13
Platform leveling switch
Adjusts platform levelness while traveling uphill/downhill on a
slope
14
Jib luffing switch (if equipped) Provides lifting/lowering control functions for the jib
15 Buzzer
The buzzer emits sound and light alarms with different
frequencies in different situations
16
Emergency stop button
When pulled to the “ON” position the machine can be started
normally.
Pushing the button to the “OFF” position will deactivate the
controller, the machine cannot be started and no function can
be activated.
17
Main boom luffing switch Controls main boom luffing movements
