CONTROLLERS AND INDICATORS
AB16EJ Plus Operation Manual 33
© March 2023
Table 6-4 (Continued)
No. Indication
Description
This icon illuminates to indicate that the axle is fully retracted/
extended.
13 DC/FE mode indicator
This icon illuminates to indicate that the FE mode is active (for
machines with hybrid power only)
14 Main boom auto-control mode indicator
This icon illuminates to indicate that the main boom enters au-
to-control mode.
15
Front wheel steering indicator
This icon illuminates to indicate that the machine enters front
wheel steering mode.
16
Rear wheel steering indicator
This icon illuminates to indicate that the machine enters rear
wheel steering mode.
17 Crab steer indicator
This icon illuminates to indicate that the machine enters the
crab steer mode.
18
Four-wheel steering indicator
This icon illuminates to indicate that the machine enters four-
wheel steering mode.
19
Fuel/battery level indicator Displays the current fuel level/battery level.
