Sinoboom AB16EJ Plus - Page 60

© March 2023
50
AB16EJ Plus Operation Manual
DIAGRAM OF DECAL POSITIONS
No.
GB-lithium
battery
GB ANSI & CSA
CE-Imperial
CE-Metric AS
Description
103011103016 103011103003
103011103009&
103011103010
103011103008 103011103014 103011103007
General diagram of decal positions
1 103008103006 103008103006 103008103006 103008103006 103008103006 103008103006
LOGO symbol (small)
2 216060000002 216060000002 216060000002 216060000002 216060000002 216060000002
Yellow & black hazard warning tape w. stripes
3–1 103011103001 103011103001 / / 103011103001 103011103001
Decal – Metric trade ID (small)
3–2 / / 103011103005 103011103005 / /
Decal – Imperial trade ID (small)
4 104011100006 104011100006 104011100006 104011100006 104011100006 104011100006
Decal – Compartment overhaul
5 103009103009 103009103009 103009103009 103009103009 103009103009 103009103009
Decal – Crushing hazard
6–1 103011103000 103011103000 / / 103011103000 103011103000
Decal – Metric trade ID (large)
6–2 / / 103011103004 103011103004 / /
Decal – Imperial trade ID (large)
7 105058103003 105058103003 105058103003 105058103003 105058103003 105058103003
LOGO SINOBOOM (small)
8 104011100002 104011100002 104011100002 104011100002 104011100002 104011100002
Decal – Lifting point
9 104011100001 104011100001 104011100001 104011100001 104011100001 104011100001
Decal – Tipping hazard
10 103011103017 103011103017 103011103017 103011103017 103011103017 103011103017
Decal – Ground pressure 4800 kg
11 103003100013 103003100013 103003100009 103003100009 103003100009 103003100009
Decal – Contact information
12 / / 103003100014 103003100014 103003100014 103003100014
Decal – Recyclable logo
13 101016100034 101016100034 101016100034 101016100034 101016100034 101016100034
Decal – Noise level of 72dB
14 104011100012 104011100012 104011100012 104011100012 104011100012 104011100012 Decal – Fall hazard 15 103007103002 103007103002 103007103002 103007103002 103007103002 103007103002
Decal – Tipping hazard
