b. using a size 2 hex key (ISO 2936:2014) unscrew two screws (M3x8),
c. carefully take out the cover and lay aside together with the screws.
5. Unscrew the screws holding the wire on the right side of the internal printer’s
housing.
6. Carefully take out the holding plate from the printer housing.
7. Holding the bearing of the Recoater, manually reposition the device to the middle
position - between Print Bed and Source Bed. This position allows access to the
left side of the Recoater’s transmission cable and space below the Recoater to
replace the parts.
8. Unscrew the two holding screws on the left side of the printer’s internal housing.
9. Take out the plate from the housing and take out the Recoater’s transmission
cable.
IMPORTANT!
Be careful! The left side of the wire is ended with a spring which is located
inside the printer’s housing.
10. After taking the wire out from the housing, remove it from the Recoater
mechanism:
a. unscrew the right end of the Recoater’s transmission cable from the plate (use
a size 2 hex key, those are the same M3x8 as in the case of the Recoater’s
casing),
b. carefully lift the Recoater and pull the wire through from the right to the center.
ATTENTION!
In case of difficulties in taking the Recoater’s transmission cable out due to
the knot or the cable lug, reposition the cable lug to the middle of the cable.
Carefully reeve first the cable lug and then the knot from the end of the cable.
11. Take out a new Recoater’s transmission cable from the package.
12. Put the new Recoater’s transmission cable through the Recoater, starting from the
left towards the center.
ATTENTION!
If the Recoater’s transmission cable does not fit between the bearing and the
roller, move the cable lug to the middle of the wire, put the cable through the
mechanism and hold the end using nippers or pliers. Carefully pull so that
the knot gets through the mechanism, and then the move the cable lug.
Repeat one more time (from the center towards the right).
67 Sinterit Lisa USER MANUAL
