SIPOS AKTORIK SIPOS 5 User Manual

Operation instructions
SIPOS 5 PROFITRON, HiMod
Page 24 Y070.020/GB
5 Commissioning
5
Commissioning
5.3 Accessing the „ commissioning“ menu;
access authorization
Parameters can only be changed in the „commissioning“ menu. Access to the „commissioning“
menu is protected by a code. This prevents accidental changing of the parameters.
The code is 9044.
The code cannot be changed. The „commissioning“ menu is accessed in four steps:
1. Select „locPar“ operation state.
2. Call up main menu.
3. Select „commissioning)“ menu.
4. Access authorization: Enter code 9044.
The operation steps are described once in the following. In the following chapters on commissio-
ning, these steps are considered as a prerequisite and will therefore not be described again.
Operation sequence
1. Select „locPar“ operation state.
xxx
locPar xxx
2. Call up main menu.
Langu./Sprache/
idioma/Lingua E
3. Select „commissioning“ menu.
commissioning
E
4. Confi rm selection. 0000 is displayed.
The fi rst zero blinks.
enter PIN-code
0
0000
h) Press
button once.
Digit 9 is blinking.
enter PIN-code
9
9000
i) Confi rm. The second zero is blinking. Confi rm.
The third zero is blinking.
enter PIN-code
90
0
00
j) Press
button four times.
Digit 4 is displayed and blinking.
enter PIN-code
90
4
40
k) Confi rm with ENTER, The last zero is blinking.
enter PIN-code
904
0
0
l) 4 Mal Taste drücken.
Ziffer 4 wird angezeigt und blinkt.
enter PIN-code
904
4
4
m) Confi rm with “ENTER”.
The display indicates „close direction“ and the
current setting in the second line.
close direction
xxx
Now, you can program the closing direction or select other parameters using the
buttons to
change the parameter values.
