Y070.020/GB Page 55
Operation instructions
SIPOS 5 PROFITRON, HiMod
6
Parameters and possible parameter values
6 Parameters and possible parameter values
Parameter Messages Explanation
state of unit
E
ready
Yes
The actuator is ready for operation can be operated from „Remote“.
(However, the „blocked in move“ fault may have occurred.)
ready
No
The actuator is not ready for operation.
(Indication also appears, if actuator is operated by hand.)
Possible fault messages are displayed one after the other using the
button. For the explanation and the possible remedy, refer to next chap-
ter 7.2.
return to menu Use ENTER to return to the „state of unit“ function.
former errors
E
The former fi ve errors are displayed (former errors 1-5),
which can consist of several fault messages each.
former errors 1
E
blocked in move
bus comm. fault
Possible indication for the last fault which has
occurred (former errors 1),
consists of 2 fault messages in this case.
return to menu Return to „former errors 1“.
former errors 2
Same as for former errors 1.
former errors 3
former errors 4
former errors 5
return to menu Return to ”former errors“.
fault signal
reset If a fault occurs, you can try to reset the fault with the ENTER button;
The „is reset!“ message is displayed for a short time and then „reset“
again.
Only faults which can be acknowledged, such as „runtime error“ are
deleted. If there are no other faults, the actuator returns to the „ready“
state. This is indicated by „ready – Yes“ once the „state of unit“ function
has been selected.
is reset! ndication appears only shortly after pressing the ENTER button. The
message indicates that faults which can be acknowledged, were dele-
ted.
TL switch
TL sw. non-act. Tripping torque/force not reached.
TL-OPEN activ Torque (force) limit in OPEN direction reached.
TL-CLOSE activ Torque (force) limit in CLOSE direction reached.
7 Status and fault signals, diagnosis
7.1 Observing ( device state and fault signals)
Via the „observing“ menu, the device state and the fault signals can be viewed in the display. Chan-
ging the values is not possible, however any occurring „fault signal“ can be reset.
The following table shows the parameters and the respective messages in accordance with the
structure of the „observing“ menu and shows the indications in the display.
The left column of the table lists the functions between which can scroll up and down using the
and buttons (refer to chapter 4.3.3, „Menu control – Navigation and changing of the parameters“).
The next column shows the possible messages. The explanations are on the right.
