SIPOS AKTORIK SIPOS 5 User Manual

Operation instructions
SIPOS 5 PROFITRON, HiMod
Page 44 Y070.020/GB
6 Parameters and possible parameter values
6
Parameters and possible parameter values
6 Parameters and possible parameter values
6.1 Valve-specifi c parameters
The following table shows the actuator parameters. The sequence matches the structure of the
„commissioning“ menu and shows the parameters in the display. Use the and buttons to scroll
up and down between these parameters (refer to „Menu control – Navigation and changing of the
parameters“ in chapter 4.3.3).
In the left column of the table, the parameters are listed with a default value, if available.
The next column shows the possible parameter values blinking in the display (you can use the
and buttons to scroll up and down between these parameters) and possibly other parameter
values. For the possible parameter values for speeds/positioning speeds/positioning times, refer to
the tables in chapter 5.4.2; for the possible parameter values for torque (force) limit refer to chapter
5.4.3.
On the right, there are possible other parameter values and supplementary explanations.
Parameter
Default value
Parameter values
Explanation
For a detailed description, refer to chapters 5.4 and 5.5
close direction
clockwise
clockwise
anti-clockwise
Direction of rotation of the output drive shaft when closing. If the closing
direction was changed, the end positions must be set afterwards.
Rotary actuator 2SA5
closing speed
Up to 7 steps Speed in CLOSE direction.
Parameterization within the speed range, refer to rating plate 7 levels whe-
re each level is 1.4 times higher than the previous one.
opening speed
Up to 7 steps Speed in OPEN direction.
Parameterization identical to speed in CLOSE direction.
em. speed (cl.)
Up to 7 steps EMERGENCY speed in CLOSE direction.
Parameterization identical to speed in CLOSE direction.
em. speed (op.)
Up to 7 steps EMERGENCY speed in OPEN direction.
Parameterization identical to speed in OPEN direction.
cut-off mode cl.
travel-dependent
travel-dependent
torque-dependent
Cut-off mode in end position CLOSED.
If the cut-off mode was changed, the end positions must (!) be set after-
wards.
cut-off mode op.
travel-dependent
travel-dependent
torque-dependent
Cut-off mode in end position OPEN.
If the cut-off mode was changed, the end positions must (!) be set after-
wards.
max. cl. torque
30 %
50 %
in 10 %-steps:
- standard (8 steps)
30–100 % Md
max
- modulating (6 steps)
from 50–100 % Md
max
Tripping torque in Nm in CLOSE direction.
max. op. torque
30 %
50 %
in 10 % steps:
- standard (8 steps)
30 – 100 % Md
max
- modulating (6 steps)
50 – 100 % Md
max
Tripping torque in Nm in OPEN direction.
Linear actuator 2SB5
Act. speed cl
Up to 7 steps Positioning speed in CLOSE direction.
Parameterization within the positioning speed range, refer to rating plate in
7 levels where each level is 1.4 times higher than the previous one.
Act. speed op
Up to 7 steps Positioning speed in OPEN direction.
Parameterization identical to positioning speed in CLOSE direction.
Act. sp.em.cl
Up to 7 steps EMERGENCY positioning speed in CLOSE direction.
Parameterization identical to positioning speed in CLOSE direction.
Act. sp.em.op
Up to 7 steps EMERGENCY positioning speed in OPEN direction.
Parameterization identical to positioning speed in CLOSE direction.
cut-off mode cl.
travel-dependent
travel-dependent
force-dependent
Cut-off mode in end position CLOSED.
If the cut-off mode was changed, the end positions must (!) be set after-
wards.
