Sirona Dental Systems GmbH 8 Patient positions
Operating Instructions C4
+
8.3 MultiMotion headrest
59 06 313 D 3382
D 3382.201.01.13.02
33
Removing the MultiMotion
For certain treatments (e.g. of children) it may be expe-
dient to remove the MultiMotion completely in order to
obtain better access to the patient. The patient's head
will then be supported on the contact surface of the
headrest extension F.
To remove the MultiMotion, proceed as follows:
1. Press release button C.
2. Pull the complete headrest out of the headrest ex-
tension.
3. Cover the opening of the headrest extension with
cover cap E.
4. If a children's head pad D is available, place it on
the headrest extension. The head pad is held mag-
netically.
NOTICE
i
The children's head pad (D) is not included in the scope
of supply, however, is available from your dental dealer.
DANGER
The children's head pad (D) contains a strong mag-
net on its bottom side. This magnet could affect any
cardiac pacemaker located nearby.
Therefore, do not allow patients, users and technical
personnel with a cardiac pacemaker to be located
near this magnet.
Furthermore, direct contact of the head pad with
magnetic cards can lead to data loss.
NOTICE
i
Deposit the removed MultiMotion in a safe place where it
cannot fall onto the floor.
Inserting the MultiMotion
To insert the MultiMotion, proceed as follows:
Check the guide of the removed headrest for con-
tamination. Remove any contamination.
Remove the cover cap E.
DANGER
Reinsert the MultiMotion in the guide from above until it
audibly locks in place.
Pull on the headrest again to make sure that it is
locked securely in place.
