The risk management (Document L5671,0012) identify the
functions of these linear actuators.
All features or functions are performed properly. Unacceptable
risks for patients, operators or others are performed and assessed
to prevent or reduce harm.
Warning against the stacking of equipment
List of cables, Length of cables, accessories
The use of this equipment adjacent to or stacked with other
equipment should be avoided because it could result improper
operation. If such use is necessary, this equipment and the other
equipment should be observed to verify that they are operating
normally.
WARNING
The use of accessories and cables other than those for which the
actuator MAX1, MAX3 and MAX64 was designed, can signifi-
cantly degrade electromagnetic EMISSIONS and IMMUNITY
performance
WARNING
Table 2
Power cables (MAX64)
Description Plug-Type Country Drawing-No Length Comment
Straight power cable Schuko DE 140306-3500 3,5 m
Straight power cable SEV CH 140316-3500 3,5 m
Straight power cable UL USA 140355-3500 3,5 m
Straight power cable Hospital grade USA 140360-3500 3,5 m
Straight power cable British standard UK 140350-3500 3,5 m
Coiled power cable Schuko DE 140342-1500 1,2/2,2 m
Coiled power cable SEV CH 140378-1200 1,2/2,2 m
Straight power cable SEV CH 140422-3500 3,5 m Polyurethane cable
Straight power cable Schuko DE 140426-3500 3,5 m Polyurethane cable
Table 1
Connection cables (MAX1, MAX3)
Description Drawing-No Type Length
Connection cable straight Jack plug 952329-1350 2 x AWG18 & 1 X AWG24 1,35 m
Connection cable straight Jack plug 952329-2650 2 x AWG18 & 1 X AWG24 2,65 m
Connection cable coiled Jack plug 952376-0001 2 x AWG18 & 1 X AWG24 0,78 m
Connection cable coiled DIN 8p 160618 2 x AWG18 0,78 m
Connection cable straight DIN 8p 160622-2650 2 x AWG18 & 5 X AWG24 1,5 m
17
