3 Connect the fork head (1) and the hinge head (2) and the ele-
ments of the application with the fastening bolts.
1 2
Fig. 17
!
Note!
Information concerning the dimensions of the drill holes
for fastening bolts can be found in the respective data sheets.
(† Appendix).
Risk of injury and material damage due to insufficient
fastening!
Only use fastening bolts and secure them adequately. Do not use
screws to install. Never loosen or otherwise manipulate screws
on actuator or options.
