3 Connect plug (1) to the connection of operating element (2) of the
device. Ensure the correct position of the arrows (3) on the plug
and on the outlet.
1
2
Fig. 25
3
Fig. 26
4 Press plug (1) down into the connection socket until the snaps (2)
lock into place on both sides.
2
1
Fig. 27
5 Ensure that both sides are mechanically locked and sealed.
6 Connect operating element to power supply. († Separate
operating manual).
49
