Section 05 TRANSMISSION
Subsection 08 (GEARBOX)
05-08-8
Do not disassemble bearings of intermediate
gears needlessly.
Pry out bottom seal
no. 33
from gearbox housing.
Remove sleeve
no. 32
then, circlip
no. 9
.
Drive out plug
no. 37
.
Remove circlip
no. 9
from LH side.
Using a press, drive out lower shaft
no. 36
from
RH side.
A29D1BA
A29D1CA
-
CAUTION
Do not push against inner bearing race.
A29D1DA
A29D1EA
