Ski-Doo Summit 583 1998 - Page 347

10-03-3
Section 10 TECHNICAL DATA
Subsection 03 (VEHICLES)
VEHICLE MODEL FORMULA Z 670 SUMMIT 500 SUMMIT 583 SUMMIT 670
ENGINE TYPE 670 494 583 670
Chain Drive Ratio 26/43 22/43 22/44 23/43
Chain
Pitch in 3/8 3/8 3/8 3/8
Type/Links Qty/Plates Qty Silent 74/13 Silent 72/11 Silent 72/13 Silent 72/13
Drive Pulley
Type of Drive Pulley TRA TRA TRA TRA
Ramp Identification 286 ➅ 285 ➄ 285 ➄ 286 ➄
Calibration Screw Position or
— calibration disc quantity
3555
Spring Color Violet/Yellow Green/Blue Green/Blue Violet/Yellow
Spring Length
± 1.5 mm
(± .060 in)
157.9
(6.22)
147.4
(5.80)
147.4
(5.80)
157.9
(6.22)
Clutch Engagement ± 200 RPM 3800 4500 4400 4100
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
7.0 (15.4)
50°
7.0 (15.4)
47°
7.0 (15.4)
50°
7.0 (15.4)
50°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
Drive Belt Part Number (P/N) 415 0990 00 415 8607 00 415 0990 00 415 0990 00
Drive Belt Width (new) ➀ mm (in) 35.0 (1-3/8) 35.3 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0)
Length cm (in) 307 (121) 345.5 (136) 345.5 (136) 345.5 (136)
Profile Height mm (in) 22.4 (.882) 36.8 (1.449) 36.8 (1.449) 50.8 (2.000)
Adjustment
Deflection
mm
(in)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track FZ 670 SC-10 Mountain SC-10 Mountain SC-10 Mountain
Ski DSA DSA DSA DSA
Length cm (in) 272.5 (107.3) 293.9 (115.7) 293.9 (114.9) 293.9 (115.7)
Width cm (in) 120.7 (47.5) 107.3 (42.3) 107.3 (42.3) 107.3 (42.3)
Height cm (in) 108 (42.5) 113 (44.5) 113 (44.5) 113 (44.5)
Ski Stance cm (in) 106.7 (42) 94 (37) 94 (37) 94 (37)
Mass (dry) kg (lb) 225 (495) 220 (484) 226 (498) 229 (503)
Ground Contact Area
cm
2
(in
2
)
6793 (1053) 7479.2 (1159.2) 7479.2 (1159.2) 7357 (1140)
Ground Contact Pressure kPa (PSI) 3.22 (.467) 2.89 (.419) 2.96 (.429) 3.05 (.442)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Impact Copolymer Impact Copolymer Impact Copolymer Impact Copolymer
Hood Material RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane RRIM Polyurethane
Battery V (A•h) N.A. N.A. N.A. N.A.
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Bulbs W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Bulbs W 3/3 N.A. N.A. N.A.
Fuse
Starter Solenoid A N.A. N.A. N.A. N.A.
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 40 (10.6) 40 (10.6) 40 (10.6) 40 (10.6)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 250 (8.5) 250 (8.5)
Cooling System ➃ L (U.S. oz) 4.7 (159) 5.0 (169) 5.0 (169) 5.0 (169)
Injection Oil Reservoir L (U.S. oz) 2.8 (95) 2.8 (95) 2.8 (95) 2.8 (95)
