Ski-Doo Summit 583 1998 - Page 348

Section 10 TECHNICAL DATA
Subsection 03 (VEHICLES)
10-03-4
VEHICLE MODEL
GRAND TOURING
500
GRAND TOURING
583
SKANDIC WT SKANDIC SWT
ENGINE TYPE 494 583 503 503
Chain Drive Ratio 23/44 23/44 N.A. N.A.
Chain
Pitch in 3/8 3/8 N.A. N.A.
Type/Links Qty/Plates Qty Silent 72/11 Silent 72/13 N.A. N.A.
Drive Pulley
Type of Drive Pulley TRA TRA TRA TRA
Ramp Identification 228 ➄ 285 ➄ 290 ➆ 146 ➄
Calibration Screw Position or
— calibration disc quantity
3334
Spring Color Blue/Green Red/Orange Yellow/Orange Red/Yellow
Spring Length
± 1.5 mm
(± .060 in)
105.7
(4.16)
91.2
(3.56)
105.7
(4.16)
87.9
(3.46)
Clutch Engagement ± 200 RPM 3600 3100 3000 2900
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
Degree
7.0 (15.4)
44°
7.0 (15.4)
47°
7.0 (15.4)
40°
6 (13.2)
40°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
32.75
(1-19/64)
32.75
(1-19/64)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 36.5 (1-7/16) 36.25 (1-27/64)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(.039 – .079)
1.0 – 2.0
(.039 – .079)
0.75 – 2.25
(.030 – .086)
1.0 – 2.0
(.039 – .079)
Drive Belt Part Number (P/N) 414 8607 00 414 8607 00 414 6338 00 414 6338 00
Drive Belt Width (new) ➀ mm (in) 35.3 (1-3/8) 35.3 (1-3/8) 34.6 (1-3/8) 34.6 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15.0) 38.1 (15.0) 50.0 (19.7) 60.0 (23.6)
Length cm (in) 345.5 (136) 345.5 (136) 396.8 (156.2) 394 (155.1)
Profile Height mm (in) 18.4 (.724) 18.4 (.724) 23.0 (.906) 23.0 (.906)
Adjustment
Deflection
mm
(in)
35 – 40
(1-3/8 – 1-3/4)
35 – 40
(1-3/8 – 1-3/4)
40 – 50
(1-9/16 – 1-31/32)
40 – 50
(1-9/16 – 1-31/32)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC-10 Touring SC-10 Touring Skandic WT Skandic WT
Ski DSA DSA Telescopic Strut Telescopic Strut
Length cm (in) 297.8 (117.2) 291.9 (114.9) 302.0 (118.9) 315.0 (124.0)
Width cm (in) 120.7 (47.5) 120.7 (47.5) 104.5 (41.1) 110.0 (43.3)
Height cm (in) 128.3 (50.5) 128.3 (50.5) 122 (48) 122 (48)
Ski Stance cm (in) 106.7 (42) 106.7 (42) 90.0 (35.4) 90.0 (35.4)
Mass (dry) kg (lb) 245 (539) 251 (553) 259 (569) 275 (605)
Ground Contact Area
cm
2
(in
2
)
7579.2 (1170) 7579.2 (1170) 10793 (1672.9) 13986 (2167.8)
Ground Contact Pressure kPa (PSI) 3.18 (.461) 3.26 (.473) 2.35 (.341) 1.93 (.280)
Frame Material Aluminum Aluminum Steel Steel
Bottom Pan Material Impact Copolymer Impact Copolymer HD Polyethylene HD Polyethylene
Hood Material RRIM Polyurethane RRIM Polyurethane RRIM Fiberglass
Battery V (A•h) 12 (22) 12 (22) 12 (22) 12 (22)
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Bulbs W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Bulbs W 3 3 N.A. N.A.
Fuse
Starter Solenoid A30302020
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 40 (10.6) 40 (10.6) 42 (11.1) 42 (11.1)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 500 (17) 500 (17)
Cooling System ➃ L (U.S. oz) 5.0 (169) 5.0 (169) N.A. N.A.
Injection Oil Reservoir L (U.S. oz) 2.8 (95) 2.8 (95) 2.55 (86) 2.55 (86)
