Ski-Doo Summit 583 1998 - Page 349

Section 10 TECHNICAL DATA
Subsection 03 (VEHICLES)
10-03-5
VEHICLE MODEL SKANDIC WT LC
ENGINE TYPE 494
Chain Drive Ratio N.A.
Chain
Pitch in N.A.
Type/Links Qty/Plates Qty N.A.
Drive Pulley
Type of Drive Pulley TRA
Ramp Identification 290 ➅
Calibration Screw Position or
— calibration disc quantity
4
Spring Color Yellow/Blue
Spring Length
± 1.5 mm
(± .060 in)
91.0
(3.58)
Clutch Engagement ± 200 RPM 3000
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
Degree
7 (15.4)
40°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
32.75
(1-19/64)
Offset
X ± 0.4 mm (± 1/64 in) 36.5 (1-27/64)
Y – X MIN. – MAX.
mm
(in)
0.75 – 2.25
(.030 – .086)
Drive Belt Part Number (P/N) 414 6338 00
Drive Belt Width (new) ➀ mm (in) 34.60 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25)
Track
Width cm (in) 50.0 (19.7)
Length cm (in) 396.8 (156.2)
Profile Height mm (in) 23.0 (.906)
Adjustment
Deflection
mm
(in)
40 – 50
(1-9/16 – 1-31/32)
Force ➂ kg (lbf) 7.3 (16)
Suspension Type
Track Skandic WT
Ski Telescopic Strut
Length cm (in) 302.0 (118.9)
Width cm (in) 104.5 (41.1)
Height cm (in) 122 (48)
Ski Stance cm (in) 90.0 (35.4)
Mass (dry) kg (lb) 285 (627)
Ground Contact Area
cm
2
(in
2
)
10793 (1673)
Ground Contact Pressure kPa (PSI) 2.59 (.376)
Frame Material Steel
Bottom Pan Material HD Polyethylene
Hood Material RRIM
Battery V (A•h) 12 (22)
Headlight W H4 60/55
Taillight and Stoplight W 8/27
Tachometer and Speedometer Bulbs W 2 x 3
Fuel and Temperature Gauge Bulbs W N.A.
Fuse
Starter Solenoid A 20
Tachometer A N.A.
Fuel Tank L (U.S. gal) 42 (11.1)
Chaincase/Gearbox mL (U.S. oz) 500 (17)
Cooling System➃ L (U.S. oz) N.A.
Injection Oil Reservoir L (U.S. oz) 2.55 (86)
