Section 2 – Maintenance Tables and DiagramsSpecifications and Features
2.2 Specifications and FeaturesTable
Model SJ20
Weight * 1107 kg (2440Ib)
Overall Width 0.80 m (31.5 in)
Overall Length 1.37 m (54 in)
Platform Size (Inside)
0.69 m x 0.91 m
(27.13 in x 35.66 in)
Platform Traversing 0.41 m (16 in)
Height
Working Height 7.77 m (25 ft 6 in)
Platform Elevated Height 5.94 m (19 ft 6 in)
Stowed Platform Height (Railings Up) 2.01 m (79.19 in)
Drive Height Full
Stowed Platform Height 0.75 m (29.7 in)
Standard Operating Times
Lift Time (Rated Load) 26 s
Lower Time (Rated Load) 26 s
Chassis
Stowed Drive Speed
4 km/h
(2.5 mph)
Elevated Drive Speed
0.5 km/h
(0.3 mph)
Gradeability (Ramp Angle [Reverse/Forward])** 25% / 25%
Tires (Solid Rubber) 10 in x 4 in
Hydraulic Oil
Type ATF Dexron III
Tank Capacity 5.3 l (1.41 gal)
* Weights are approximate; refer to the serial nameplate for the specific weight.
** Refer to Section 6.4: Move the MEWP for Transport in the operation manual for more details.
2064AA
