Skyjack SJ20 Service Manual

59
SJ20 238886ABA
Section 4 – Troubleshooting InformationElectrical System
4.2-9 No Lift/Lower from Platform Controls
1. Loose or broken 09 wire from lift/off/drive switch
S3 to joystick pin P-23
Check continuity. Replace if defective.
2. Open or defectivelift/off/drive switch S3 Close switch. Replace if defective
4.2-10 No Steer Left
1. Loose or broken wire 24 from steer coil 4H-24 to
machine controller pin A1
Check continuity. Replace if defective.
2. Defective coil 4H-24 Replace coil
3. Defective left steer switch or wiring on upper contol
joystick
Check wiring and switch. Repair or replace if
defective.
4.2-11 No Steer Right
1. Loose or broken wire 23 from steer coil 3H-23 to
machine controller pin A24
Check continuity. Replace if defective.
2. Defective coil 4H-23 Replace coil
3. Defective right steer switch or wiring on upper contol
joystick
Check wiring and switch. Repair or replace if
defective.
4.2-12 No Drive
1. Loose or broken 12 wire from lift/off/drive switch
S3 to joystick pin P-07
Check continuity. Replace if defective.
2. Open or defectivelift/off/drive switch S3 Close switch. Replace if defective
3. Loose or broken 05A wire from base E-stop S28 to to
30ACR brake relay pin 30 and/or pin 86
Check continuity. Replace if defective.
4. Loose or broken 30A wire from 30ACR brake relay pin
85 to machine controller pin B-22
Check continuity. Replace if defective.
5. Defective 30ACR brake relay
Check relay Replace if defective.
6. Loose or broken 05B from diode D05B to brake BK1
pin P7-1 and/or BK2 pin P9-1
Check continuity. Replace if defective.
7. Loose or broken wire 30L from BK2 pin P9-2 to
machine controller pin A30
Check continuity. Replace if defective.
8. Loose or broken wire 30R from BK1 pin P7-2 to
machine controller pin A28
Check continuity. Replace if defective.
9. Defective brake BRK1 or BRK2
Check brakes. Replace if defective.
