Skyjack SJ20 Service Manual

36
SJ20238886ABA
Section 3 – System Component Identification and Schematics Wire Number and Color Code
3.3 Wire Number and Color Code
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
WIRE
NO.
WIRE
COLOR
00 WHT 21 GRN/BLK 42 PNK/BLU 84 YEL/BRN 1002 RED/BLK
000 WHT 21 WHT/RED 43 PNK/RED 85 ORG/BLK/WHT 1003 ORG
B1 BLU/PINK 22 ORG/BLU 44 PNK/ORG 87 BRN/ORG 1006 BLU
01 PUR/BLK 23 BLK/WHT/RED 49 GRN 88 BRN/PNK 1008 GRY
02 WHT 23 BLK/WHT 50 BRN/WHT 89 BRN/GRN 1100 BLK
03 GRN/PUR 24 BLU/BLK 55 GRY/RED 99 PUR/RED 1103 ORG
04 RED/YEL 25 ORG/GRN 56 WHT/ORG 100 RED 2001 BRN
05 PUR/BLACK 26 GRN 57 BLK/WHT 101 2002 RED
06 27 BLK 59 ORG/BLK 102 PNK 2005 GRN/WHT
07 RED 28 GRN/RED 60 BLK/RED/GRN 103 RED 3008 GRY
08 PUR/WHT 29 BLU/YEL 71 BLU/RED 103B BLK 4002 RED
09 ORG/RED 30 BRN 72 WHT/BLK/RED 103C WHT 7002 RED
10 BLU/WHT 31 RED/WHT 73 WHT/RED/GRN 104 RED
11 YEL/BLK 32 GRN/BLK 74 BLK/RED/GRN 105 GRN
12 BRN/RED 33 75 WHT/RED/GRN 106 BLU
13 ORG 34 GRN/WHITE 76 RED/GRN 200 BLK/WHT
14 BLK 35 RED/BRN 77 GRN/BLK/WHT 203 ORG/BLK
15 BLU 36 YEL 78 RED/BLK/WHT 205 GRN
16 WHT/BLK 37 GRN/WHT 79 YEL/PNK 209 WHT/BLK
17 BLU/RED 38 80 YEL/PUR 900 WHT
18 RED/BLK 39 GRN/WHT 81 YEL/RED 902 WHT
19 ORG/BLK 40 PNK/YEL 82 YEL/BLU 910 BLK
20 BLK/WHT/RED 41 PNK 83 YEL/ORG 1001 BRN/WHT
This table is to be used as a wire number/color reference for electrical drawings and schematics.
All wire numbers will retain their original color coding, for example if wire 7 is red, wire 7A, 7B, and 7C will also be red.
