39
SJ20 238886ABA
Section 3 – System Component Identification and SchematicsHydraulic Connections
S2
Left
Steer
Right
Steer
S1
3.6 Hydraulic Connections
M234628AA
Steer Cylinder
Power Unit
Lift Cylinder
