Skyjack SJ20 Service Manual

37
SJ20 238886ABA
Section 3 – System Component Identification and SchematicsHydraulic Parts List
3.4 Hydraulic Parts List
Index
No.
Skyjack
Part No.
Description
2H-13 151683 COIL, 24 V DT with diode
3H-14 234717 COIL, 24 V
4H-23/24 234717 COIL, 24 V
C1-4 234130 CYLINDER, Multistage with cushion
C1-5 234078 STEER CYLINDER
CV1 234711 VALVE, Check
F1 234269 FILTER, 7 Micron return
F2 234270 FILTER, 7 Micro return
MB1 234720 MANIFOLD, SJ20 Main
OR1 234654 VALVE, Flow control
P1 234703 PUMP, 3.59 CC gear
RV1 234715 VALVE, 2000 PSI relief
RV2 234716 VALVE, 3000 PSI cross port relief
SV1 234713 VALVE, 2P3W cartridge
SV2 234714 VALVE, 2P4W cartridge
SV3 151696 VALVE, Emergency lowering
