Skyjack SJ20 Service Manual

83
SJ20 238886ABA
Section 5 – ProceduresLift Cylinder Removal
5.9 Lift Cylinder Removal
1. Disconnect the electrical connector from the
holding valve coil at the bottom of the lift cylinder.
2. Disconnect the hydraulic hose from the bottom of
the holding valve manifold. Put a cap and plug on
all open hydraulic ports and fittings.
3. Remove and set aside the hardware from the
bottom of the chassis that secures the lift cylinder.
4. Remove and set aside the hardware from the
bottom of the chassis that secures the lift cylinder.
