Section 2 – Maintenance Tables and DiagramsFloor Loading Pressure ANSI/CSA
2.4 Floor Loading Pressure ANSI/CSATable
Model
Total MEWP
Weight
Total MEWP Load
Wheel** LCP*** OFL***
SJ20
min* 1107 kg (2440 lb) 276 kg (609 lb) 792 kPa (115 psi) 9.9 kPa (207 psf)
max* 1264 kg (2787 lb) 426 kg (940 lb) 1021 kPa (148 psi) 11.3 kPa (237 psf)
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Max: Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole
surface directly underneath the chassis. This has been calculated by dividing the MEWP weight by the
overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must
be able to withstand more than the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is
generally determined by the engineer or architect for that particular structure.
WARNING
Do not use tires other than the tires that Skyjack
specifies for this MEWP. Do not mix different types
of tires or use tires that are not in good condition.
Only replace the tires with the same types that are
approved by Skyjack. The use of other tires can
make the MEWP less stable. If you do not obey,
there is a risk of death or serious injury.
