Skyjack SJ20 Service Manual

38
SJ20238886ABA
Section 3 – System Component Identification and Schematics Electrical Parts List
Index
No.
Skyjack
Part No.
Description
30ACR 108589 RELAY, Brake
2H-13 151683 COIL, 24 V with Diode
3H-14 234717 COIL, 24 V -Lift
4H-23/24 234717 COIL, 24 V - Steer
B1/B2 169938 BATTERY, 12 V
103480 BATTERY, 6 V (Optional)
BCI 122093 INDICATOR, Batterty charge
BP-29 215817 BEEPER
C1 146475 MOTOR CONTACTOR
CB1/CB2 117325 CIRCUIT BREAKER, 15A
CHARGER 234250 DELTAQ CHARGER
CM1 234005 CONTROLLER, ZAPI 3IN1
DXX 234227 DIODE, Schottky 30V 3A
DS1 234006 ZAPI DISPLAY
F1 216103 FUSE, 300A
FL-1 234591 DUAL FLASHING LIGHTS
H1 146649 HORN, 24V - Low tone
J11 213098 TELEMATICS (Optional)
LS1 199405 LIMIT SWITCH, Base
LS3 234218 LIMIT SWITCH, Platform service position
LS4 234219 LIMIT SWITCH, Platform deck extended position
M1 234158 POWER UNIT
M2 234150 MOTOR, Right Traction
M3 234150 MOTOR, Left Traction
S1 119725 SWITCH, Main disconnect
S2 147054 SWITCH, Base - Lift/lower
S3 234118 SWITCH, Platform - Lift/Off/Drive
S4 147053 SWITCH, Emergency stop - Platform control
S5 115573 SWITCH, Toggle - Diagnostic
S6 115573 SWITCH, Toggle - Brake release
S7 171911 SWITCH, Toggle - Outdoor option (Optional)
S8 147054 SWITCH, Platform horn
S9 220494 SWITCH, SGLE option (Optional)
S10 149536 SWITCH, Base - Idle/Platform/Base
S28 147053 SWITCH, Emergency stop - Base control
3.5 Electrical Parts List
