102
SJ30AJE, SJ30ARJE196274AF
Section 4 – Troubleshooting Information Electrical System
18. Loose or broken wire #4 (2 places) or #8 from
platform terminal block to 208CR1 relay.
Check continuity. Replace if defective.
19. Defective relay 208CR1. Check relay. Replace if defective.
4.2-22 No Boom Up from Platform Control Console
1. Loose or broken wire #04 from platform terminal
block to joystick controller A2.
2. Loose or broken wire #02 from platform terminal
block to joystick controller A2.
Check continuity. Replace if defective.
3. No output on y-axis of joystick controller A2.
4. Loose or broken wire “Y” from joystick controller
A2 to valve driver pin #29.
Check continuity. Replace if defective.
5. No output on pin #12 of the valve driver to wire
#70.
Check pin #12 for proportional voltage. If no
voltage present with foot on footswitch check
section 5 for OCM pin voltage reference.
6. No output on pin #22 of the valve driver to wire
#14.
Check pin #22 for minimum 7 volts. If no voltage
present with foot on footswitch check section 5 for
OCM pin voltage reference.
7. Loose or broken wire #14 from valve driver pin
#22 to plug A pin #7 in platform control console.
Check continuity. Replace if defective.
8. Loose or broken wire #14 in boom cable A or its
connectors.
Check for continuity between pins #7 on cable A.
Check for loose or corroded connections on cable
connectors. Replace if wire is defective.
9. Loose or broken wire #14 from base connector
plug A pin #7 to base terminal block.
Check continuity. Replace if defective.
10. Loose or broken wire #14 from base terminal
block to main manifold harness.
Check continuity. Replace if defective.
11. Loose or broken wire #14 from main harness to
boom up valve 4H-14.
Check continuity. Replace if defective.
12. Loose or broken wire #02 from main harness to
boom up valve 4H-14.
Check continuity. Replace if defective.
13. Defective boom up valve coil 4H-14. Check continuity and resistance through coil.
Replace if defective.
