SJ30AJE, SJ30ARJE 196274AF
Specifications and Features - ANSI/CSA Section 2 – Maintenance Tables and Diagrams
2.10 Specifications and Features - ANSI/CSATable
SJ30AJE
ANSI/CSA
SJ30ARJE
ANSI/CSA
Height and
Reach Data
Working Height - maximum 36' 3" 11.1 m 36' 1" 11.0 m
Platform Height - maximum 29' 8" 9.04 m 29' 6" 9.00 m
Up & Over Clearance - at Main Boom 13' 1" 4.00 m 13' 5/8" 3.98 m
Horizontal Reach - maximum 20' 7" 6.27 m 20' 6-5/8" 6.26 m
Horizontal Reach - Retracted 16' 9" 5.11 m 16' 8-5/8" 5.10 m
Tailswing 0" 0 m 0" 0 m
Platform
Data
Platform Size 30" x 46" 0.76 x 1.17 m 30" x 46" 0.76 x 1.17 m
Platform Rotation 180° 180° 180° 180°
Platform Height - Stowed 1' 3" 0.38 m 1' 0.30 m
Overall Railing Height 4' 6" 1.37 m 4' 6" 1.37 m
Platform Railing Height 3' 7-1/2" 1.10 m 3' 7-1/2" 1.10 m
Dimensional
Data
Height - stowed 6' 6" 1.98 m 6' 6" 1.98 m
Length - stowed 18' 2" 5.64 m 18' 1" 5.51 m
Height - transport 8' 3" 2.51 m 8' 2" 2.49 m
Length - transport 13' 1" 3.99 m 12' 5" 3.78 m
Width 3' 11" 1.19 m 3' 11" 1.19 m
Wheelbase 5' 5" 1.80 m 5' 5" 1.80 m
Ground Clearance (Chassis) 4" 0.10 m 4" 0.10 m
Turning Radius (Inside, Left - Right) 5' 1/2" - 5' 5" 1.54 x 1.65 m 5' 1/2" - 5' 5" 1.54 x 1.65 m
Turning Radius (Outside, Left - Right) 10' 6" - 10' 11" 3.20 x 3.33 m 10' 6" - 10' 11" 3.20 x 3.33 m
Turning Angle 76° 76° 76° 76°
Turret Rotation 352° 352° 352° 352°
Jib Data
Jib Length 4' 1" 1.24 m 4' 1" 1.24 m
Jib vertical Range of Motion 7' 8" 2.34 m 7' 8" 2.34 m
Jib Range - Up 77.5° 77.5° 77.5° 77.5°
Jib Range - Down 65.5° 65.5° 65.5° 65.5°
Jib rotation N/A N/A 180° 180°
Boom Data
Boom Up Angle 75° 75° 75° 75°
Boom Down Angle 5° 5° 5° 5°
Lift Capacity
Lift Capacity - Indoor 500 lbs 226 kg 500 lbs 226 kg
Lift Capacity - Outdoor 500 lbs 226 kg 500 lbs 226 kg
Number of Persons - Indoor 2 2 2 2
Number of Persons - Outdoor 1 1 1 1
Wind rating 41 ft/s 12.5 m/s 41 ft/s 12.5 m/s
