Section 2 – Maintenance Tables and Diagrams Hydraulic Specifications
SPECIFICATIONS
SJ30AJE/ARJE
US Imperial Metric
Cylinders
Slave Cylinder
Bore 3 in 7.5 cm
Rod Diameter 1.57 in 4.0 cm
Stroke 11.7 in 29.6 cm
Maximum Operating Pressure 3000 psi 207 bar
Test Pressure 3000 psi 207 bar
Jib Cylinder
Bore 1.77 in 4.5 cm
Rod Diameter 1.38 in 3.5 cm
Stroke 22.2 in 56.4 cm
Maximum Operating Pressure 2000 psi 138 bar
Test Pressure 3000 psi 207 bar
Steer Cylinder
Bore 2 in 5.0 cm
Rod Diameter 1 in 2.5 cm
Stroke 7.44 in 18.9 cm
Maximum Operating Pressure 2000 psi 138 bar
Test Pressure 3000 psi 207 bar
Hydraulic Oil
Standard
Shell Tellus T46
Petro-Canada Hydrex MV46
-15°F to 100°F -26°C to 38°C
Biodegradable Shell Naturelle HF-E 46 -4°F to 194°F -20°C to 90°C
Hydraulic Tank Capacity 4.3 gal 16.2 L
2.9 Hydraulic SpecificationsTable
