SJ30AJE, SJ30ARJE 196274AF
Hydraulic Specifications Section 2 – Maintenance Tables and Diagrams
2.9 Hydraulic SpecificationsTable
1211AD-1
SPECIFICATIONS
SJ30AJE/ARJE
US Imperial Metric
Pumps
Main Pumps
Pressure 3300 psi 228 bar
Displacement 0.155 CI 2.54 CC
Emergency Pump
Pressure 3250 psi 224 bar
Displacement 0.073 CI 1.19 CC
Filter Return Line Filter Pressure 25 psi 1.724 bar
Motor Swing Drive Motor
Flow 3.05 gal/m 11.55 L/min
Pressure 1774 psi 12.23 MPa
Rotary
Actuators
Platform Rotary Actuator
Displacement 8.05 CI 132 CC
Pressure 3000 psi 207 bar
Jib Rotary Actuator
Displacement 14.3 CI 234.3 CC
Pressure 3000 psi 207 bar
Cylinders
Extension Cylinder
Bore 1.96 in 5.0 cm
Rod Diameter 1.38 in 3.5 cm
Stroke 46 in 116.8 cm
Maximum Operating Pressure 1250 psi 86 bar
Test Pressure 3000 psi 207 bar
Main Boom Lift Cylinder
Bore 3.15 in 8.0 cm
Rod Diameter 1.77 in 4.5 cm
Stroke 2400 psi 56.6 cm
Test Pressure 3000 psi 207 bar
Riser Cylinder
Bore 2.36 in 6.0 cm
Rod Diameter 1.77 in 4.5 cm
Stroke 27.87 in 70.8 cm
Maximum Operating Pressure 2000 psi 138 bar
Test Pressure 3000 psi 207 bar
Master Cylinder
Bore 3 in 7.5 cm
Rod Diameter 1.57 in 4.0 cm
Stroke 11 in 28.3 cm
Maximum Operating Pressure 3000 psi 207 bar
Test Pressure 3000 psi 207 bar
1211AD-1
