Skyjack SJ30ARJE User Manual

39
SJ30AJE, SJ30ARJE 196274AF
Specifications and Features - CE, AS & KC Section 2 – Maintenance Tables and Diagrams
SJ30ARJE
CE
SJ30ARJE
AS
SJ30ARJE
KC
Height and
Reach Data
Working Height - maximum 11.0 m 11.0 m 11.0 m
Platform Height - maximum 9.00 m 9.00 m 9.00 m
Up & Over Clearance - at Main Boom 4.00 m 4.00 m 4.00 m
Horizontal Reach - maximum 6.26 m 6.26 m 6.26 m
Horizontal Reach - Retracted 5.10 m 5.10 m 5.10 m
Tailswing 0 m 0 m 0 m
Platform
Data
Platform Size 0.76 x 1.17 m 0.76 x 1.17 m 0.76 x 1.17 m
Platform Rotation 180° 180° 180°
Platform Height - Stowed 0.30 m 0.30 m 0.30 m
Overall Railing Height 1.37m 1.37 m 1.37 m
Platform Railing Height 1.10 m 1.10 m 1.10 m
Dimensional
Data
Height - stowed 1.98 m 1.98 m 1.98 m
Length - stowed 5.51 m 5.51 m 5.51m
Height - transport 2.50 m 2.50 m 2.50 m
Length - transport 3.80 m 3.80 m 3.8 m
Width 1.19 m 1.19 m 1.19 m
Wheelbase 1.65 m 1.65 m 1.65 m
Ground Clearance (Chassis) 0.01 m 0.01 m 0.01 m
Turning Radius (Inside, Left - Right) 1.53 - 1.65 m 1.53 - 1.65 m 1.53 - 1.65 m
Turning Radius (Outside, Left - Right) 3.21 - 3.32 m 3.21 - 3.32 m 3.21 - 3.32 m
Turning Angle 76° 76° 76°
Turret Rotation 352° 352° 352°
Jib Data
Jib Length 1.24 m 1.24 m 1.24 m
Jib vertical Range of Motion 2.34 m 2.34 m 2.34 m
Jib Range - Up 77.5° 77.5° 77.5°
Jib Range - Down 65.5° 65.5° 65.5°
Jib rotation 180° 180° 180°
Boom Data
Boom Up Angle 75° 75° 75°
Boom Down Angle 5° 5° 5°
Lift Capacity
Lift Capacity - Indoor 227 kg 227 kg 227 kg
Lift Capacity - Outdoor 227 kg 227 kg 227 kg
Number of Persons - Indoor 2 2 2
Number of Persons - Outdoor 1 1 1
Wind rating 12.5 m/s 12.5 m/s 12.5 m/s
1385AA-1
2.11 Specifications and Features - CE, AS & KCTable
