Section 2 – Maintenance Tables and Diagrams Specifications and Features - ANSI/CSA
SJ30AJE
ANSI/CSA
SJ30ARJE
ANSI/CSA
Performance
and Speeds
Gradeability - Maximum 35% 35% 35% 35%
Drive Speed - Stowed 3.0 mph 4.8 km/h 3.0 mph 4.8 km/h
Drive Speed - Elevated 0.4 mph 0.6 km/h 0.4 mph 0.6 km/h
Turret Rotation Time 70-90 s 70-90 s 70-90 s 70-90 s
Platform Rotation Time 7-10 s 7-10 s 7-10 s 7-10 s
Main Boom Up Time 20-24 s 20-24 s 20-24 s 20-24 s
Main Boom Down Time 18-20 s 18-20 s 18-20 s 18-20 s
Fly Boom Extend Time 17-19 s 17-19 s 17-19 s 17-19 s
Fly Boom Retract Time 12-16 s 12-16 s 12-16 s 12-16 s
Riser Up Time 14-18 s 14-18 s 14-18 s 14-18 s
Riser Down Time 22-26 s 22-26 s 22-26 s 22-26 s
Jib Swing Time 14-16 s 14-16 s 14-16 s 14-16 s
Jib Up Time 18-20 s 18-20 s 18-20 s 18-20 s
Jib Down Time 12-16 s 12-16 s 12-16 s 12-16 s
Steer Left/Right Time 2-4 s 2-4 s 2-4 s 2-4 s
Tire Data
Tire Size 22" x 7" 5.59 x 1.78 m 22" x 7" 5.59 x 1.78 m
Diameter, Outside 22" 5.59 m 22" 5.59 m
Width 7" 1.78 m 7" 1.78 m
Electrical
Data
Battery Voltage 48V DC 48V DC 48V DC 48V DC
Battery Type Lead/Acid Lead/Acid Lead/Acid Lead/Acid
Weights &
Pressure
Data
Overall Weight - No Options 14580 lbs 6613 kg 14580 lbs 6613 kg
Wheel Load - Transport with No Load 4220 lbs 1914 kg 4220 lbs 1914 kg
Wheel Load - Maximum with Load 7750 lbs 3515 kg 7750 lbs 3515 kg
LCP - Transport with No Load 161 psi 1110 kPa 161 psi 1110 kPa
LCP - Maximum with Load 236 psi 1627 kPa 236 psi 1627 kPa
OUP - No Load 513 lb/ft² 24.6 kPa 513 lb/ft² 24.6 kPa
OUP - With Load 530 lb/ft² 25.4 kPa 530 lb/ft² 25.4 kPa
1384AA-2
2.10 Specifications and Features - ANSI/CSATable

Skyjack SJ30ARJE Specifications

General

Brand	Skyjack
Model	SJ30ARJE
Category	Boom Lifts
Language	English
