29
SJ30AJE, SJ30ARJE 196274AF
MEWP Torque Specifications Section 2 – Maintenance Tables and Diagrams
Location Description
Torque
ft-lb Nm
Base
Drive Motor BOLT, Hex head (1/2"-13 x 1.75", Grade 8) 75-85 102-115
Torque Hub BOLT, Hex head (5/8"-11 x 1.75", Grade 8) 170 230
Wheel Nut (torque hub) NUT, Wheel (5/8"-18) 180 244
Wheel Nut (free spinning hub) NUT, Wheel (5/8"-18) 180 244
Swing Drive BOLT, Hex head (5/8"-11 x 4.00", Grade 8) 170 230
Turret
Ring Gear BOLT, Hex head (5/8"-11 x 4.00", Grade 8) 170 230
Turret Counterweight BOLT, Hex Head (3/4"-10 x 3.00", Grade 8) 250 339
Riser Counterweight BOLT, Hex head (3/8"-16 x 3.25", Grade 5) 30 41
Cylinders
Main Lift
PISTON 578 784
PISTON SET SCREW 11 15
GLAND 491 666
Extension
ROD NUT 289 392
GLAND 318 431
Master
PISTON 542 735
PISTON SET SCREW 11 15
GLAND 462 626
Slave
ROD NUT 289 392
GLAND 462 626
Riser
PISTON 434 588
PISTON SET SCREW 6 8
GLAND 376 510
Jib
PISTON 324 439
PISTON SET SCREW 6 8
GLAND 318 431
Steer
PISTON 361 489
PISTON SET SCREW 6 8
GLAND 318 413
Jib
Rotary Actuator
BOLT, Hex head, patch (3/8"-16 x 0.875", Grade 8) 35 47
NUT, Torque Lock (1-8, Grade 3) 770 1044
Platform
Rotary Actuator
BOLT, Hex head, patch (3/8"-16 x 0.75", Grade 8) 35 47
NUT, Torque Lock (3/4"-10, Grade C) 380 512
Load Cell
BOLT, Hex head (1/2"-13 x 2.25", Grade 8) 80 108
BOLT, Hex head patch (ZP, M16 x 1.5 x 4.5, Grade 8.8) 130 177
1388AC
2.2 MEWP Torque SpecificationsTable
