Section 5 – Procedures Platform
5.2-5 How to Adjust the SCM Pump Motor Speed
Continued from the previous page.
Function
JibRotate
Plat.Rotate
Plat.Level
RiserUp
Turret
BoomUp
TeleIn
TeleOut
JibUp
JibDown
BoomDown
Function
Setting
(Min/Max)
JibRotate 13%/25%
Plat.Rotate 13%/20%
Plat.Level 35%/35%
RiserUp 30%/100%
Turret 15%/60%
BoomUp 15%/100%
TeleIn 15%/55%
TeleOut 15%/100%
JibUp 17%/32%
JibDown 15%/27%
BoomDown 15%/50%
NOTE: 1. Recycle power to the OCM with the e-stop to re-enable the password protection.
2. If the OCM is inactive for more than 5 minutes, the password must be re-entered.
1216AB
MotorSpeeds
SET PMU MOD PCT
PRESS SELECT
(FLASHING)
JIB ROT FNCT
(MAX)
(FLASHING)
Increases
Value
TOGGLE
(%)
(JIB ROTATE FNCT)
(FLASHING)
(PLAT ROT FNCT)
(FLASHING)
JIB ROT FNCT
(MIN)
(FLASHING)
Once the value has been
adjusted within the
parameter of the function
selected, you may continue
to another adjustable
parameter or save/exit all
the way out to the start
screen.
MENU
▬▬▬▬
SELECT
▲
▬▬▬
┼
▲
▬▬▬
┼
MENU
▬▬▬▬
SELECT
MENU
▬▬▬▬
SELECT
▲
▬▬▬
┼
▬
▬▬▬
▼
MENU
▬▬▬▬
SELECT
Decreases
Value
▲
▬▬▬
┼
(%)
