HGMS62 Split Type Genset Controller User Manual Page 27 of 58
No.
Items
Range
Default
Description
2
Flywheel Teeth
(1.0-300.0)
118.0
Flywheel teeth on the engine, used for
judging starter disconnect conditions
and detecting engine speed, see
following installation description.
3
Rated Speed
(0-6000)r/min
1500
Provide standard for over/under/loading
speed.
4
Idle Speed
(0-3000)r/min
750
Engine speed in idle status.
5
Loading Speed
(0-100)%
90
Set value is percentage of rated speed,
controller detects it as taking load. When
the speed is lower than loading speed, it
will not enter normal running.
6
Speed Signal Loss
Delay
(0-3600)s
5
Time from speed is 0 to confirm action.
7
Speed Signal Loss
Action
(0-1)
0
0: Warning; 1: Shutdown.
8
Over Speed Shutdown
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
114
Set value: engine rated speed PCT.
(0-3600)s
2
Confirm time for over speed shutdown
detection.
9
Under Speed
Shutdown
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
80
Set value: engine rated speed PCT.
(0-3600)s
3
Confirm time for under speed shutdown
detection.
10
Over Speed Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
110
Set value: engine rated speed PCT.
(0-200)%
108
Return value: engine rated speed PCT.
(0-3600)s
5
Confirm time for over speed warning
detection.
11
Under Speed Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
86
Set value: engine rated speed PCT.
(0-200)%
90
Return value: engine rated speed PCT.
(0-3600)s
5
Confirm time for under speed warning
detection.
12
Battery Voltage
(0-60.0)V
24.0
Provide standard for battery over/under
voltage.
13
Over Volt Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
120
Set value: battery rated volt PCT.
(0-200)%
115
Return value: battery rated volt PCT.
(0-3600)s
60
Confirm time for battery over volt
detection.
14
Under Volt Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
85
Set value: battery rated volt PCT.
