Smartgen HGMS62 User Manual

HGMS62 Split Type Genset Controller User Manual Page 29 of 58
No.
Items
Range
Default
Description
27
Battery Under Volt
Start Value
(1.0-60.0)V
10.0
Set value is battery under voltage start
value, which is active in auto mode.
28
Battery Under Volt
Stop Value
(1.0-60.0)V
24.0
Set value is battery under voltage stop
value after charging, which is active in
auto mode.
29
Battery Under Volt
Start/Stop Delay
(0-3600)s
60
When battery voltage reaches start
threshold, genset will start after delay;
when battery voltage reaches stop
threshold, genset will stop after delay.
Generator Setting
1
Supply System
(0-3)
0
0: 3P4W;
1: 3P3W;
2: 2P3W;
3: 1P2W.
2
Poles
(2-64)
4
Generator pole numbers. It can be used
for calculating engine speed without
speed sensor.
3
Rated Voltage
(30-30000)V
230
Provide standard for gen
over/under/loading voltage. If PT is
used, it is PT secondary voltage.
4
Loading Voltage
(0-200)%
85
Set value is gen rated voltage
percentage, controller detects it as
taking load. When gen voltage is lower
than the loading voltage, it will not enter
normal running.
5
Rated Frequency
(10.0-75.0)Hz
50.0
Provide standard for over/under/loading
frequency.
6
Loading Frequency
(0-200)%
85
Set value is gen rated frequency
percentage, controller detects it as
taking load. When gen frequency is
lower than the loading frequency, it will
not enter normal running.
7
PT Set
(0-1)
0
0: Disable; 1: Enable.
(30-30000)
100
Primary.
(30-1000)
100
Secondary.
8
Gen Over Volt
Shutdown
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
120
Set value: gen rated voltage PCT.
(0-3600)s
3
Confirm time for gen over voltage
shutdown detection.
9
Gen Under Volt
Shutdown
(0-1)
0
0: Disable; 1: Enable.
(0-200)%
80
Set value: gen rated voltage PCT.
