HGMS62 Split Type Genset Controller User Manual Page 30 of 58
No.
Items
Range
Default
Description
(0-3600)s
3
Confirm time for gen under voltage
shutdown detection.
10
Gen Over Freq.
Shutdown
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
114
Set value: gen rated frequency PCT.
(0-3600)s
2
Confirm time for gen over frequency
shutdown detection.
11
Gen Under Freq.
Shutdown
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
80
Set value: gen rated frequency PCT.
(0-3600)s
3
Confirm time for gen under frequency
shutdown detection.
12
Gen Over Volt Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
110
Set value: gen rated voltage PCT.
(0-200)%
108
Return value: gen rated voltage PCT.
(0-3600)s
5
Confirm time for gen over voltage
warning detection.
13
Gen Under Volt
Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
84
Set value: gen rated voltage PCT.
(0-200)%
86
Return value: gen rated voltage PCT.
(0-3600)s
5
Confirm time for gen under voltage
warning detection.
14
Gen Over Freq.
Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
110
Set value: gen rated frequency PCT.
(0-200)%
108
Return value: gen rated frequency PCT.
(0-3600)s
5
Confirm time for gen over frequency
warning detection.
15
Gen Under Freq.
Warning
(0-1)
1
0: Disable; 1: Enable.
(0-200)%
84
Set value: gen rated frequency PCT.
(0-200)%
86
Return value: gen rated frequency PCT.
(0-3600)s
5
Confirm time for gen under frequency
warning detection.
16
Loss of Phase Set
(0-1)
1
0: Disable; 1: Enable.
17
Reverse Phase Set
(0-1)
1
Load Setting
1
CT Ratio
(5-6000)/5
500
External CT ratio.
2
Rated Current
(5-6000)A
500
Generator rated current, used for judging
load current.
3
Rated Power
(0-6000)kW
276
Generator rated power, used for judging
load power.
4
Over Current Enable
(0-1)
1
0: Disable; 1: Enable.
