Smartgen HGMS62 User Manual

HGMS62 Split Type Genset Controller User Manual Page 31 of 58
No.
Items
Range
Default
Description
and Threshold
(0-200)%
120
Set value is gen rated current
percentage, delay value can be set DMT
or IDMT, action type can be set as
warning, shutdown, trip and stop, trip.
(0-3)
2
0: Warning; 1: Shutdown; 2: Trip and
Stop; 3: Trip.
5
Over Current Delay
(0-1)
0
0: DMT; 1: IDMT
(0-3600)s
10
Delay
(1-36)
36
Delay rate
6
Reverse Power Set
(0-1)
0
0: Disable; 1: Enable.
(0-200)%
10
Set value: load rated power percentage.
(0-200)%
5
Return value: load rated power
percentage.
(0-3600)s
5
Confirm time for reverse power
detection.
7
Reverse Power Action
(0-3)
0
0: Warning; 1: Shutdown; 2: Trip and
Stop; 3: Trip.
8
Over Power Set
(0-1)
0
0: Disable; 1: Enable.
(0-200)%
110
Set value: load rated power percentage.
(0-200)%
105
Return value: load rated power
percentage.
(0-3600)s
5
Confirm time for over power detection.
9
Over Power Action
(0-3)
0
0: Warning; 1: Shutdown; 2: Trip and
Stop; 3: Trip.
Breaker Setting
1
Transfer Time
(0-7200)s
5
Interval time from mains open to gen
close or from gen open to mains close.
2
Close Time
(0-20.0)s
5.0
Pulse width of mains close and gen
close. When it is 0, it means continuous
output.
3
Open Time
(0-20.0)s
3.0
Pulse width of mains open and gen
open.
4
Detection Time
(0-20.0)s
5.0
Breaker auxiliary contact detection time
after ATS transferring.
5
Transfer Failure
Warning
(0-1)
0
0: Disable; 1: Enable.
6
Open Detection
(0-1)
0
7
Fast Trip in Mains
Abnormal
(0-1)
1
0: Disable; 1: Enable.
Module Setting
1
Power-on Mode
(0-2)
0
0: Stop Mode; 1: Manual Mode; 2: Auto
Mode.
