SMC Networks HRR012-A*-20 Series User Manual

HRX-OM-W002-A
Chapter 3 Transport and Setting Up
HRR Series 3.4 Piping
3-21
5. In case of water-cooled type, please also connect the piping of the facility water inlet
and outlet of the customer’s water source equipment.
Recommended piping circuit
Fig. 3-10 Recommended piping circuit
№
Description
Size
1
Valve
Rc1/2
2
Pressure gauge
0 to 1.0MPa
3
Pipe,hose,etc.
inside diameter Φ15 or more
Thermo-chiller
Circulating fluid
return port
Circulating fluid
outlet
Facillity water outret
(Water-cooled refrigeration)
Facillity water inlet
(Water-cooled refrigeration)
User's
equipment
1
1
1
1
1
1
2
Facility
water
branch
1
Tightening
torque
Rc1/2：28 to 30N・m
Rc3/8：22 to 24N・m
To the inlet
へ
From the outlet
From the user’s
water source outlet
To the user’s
water source inlet
Circulating fluid outlet
Rc1/2
Circulating fluid Return port
Rc1/2
Facility water inlet
Rc3/8
Facility water outlet
Rc3/8
