HRX-OM-X010
Chapter 3 Transporting and Installation
3.3 Procedure for Installation HRZ Series
3-10
HRZ008-L-F HRZ008-L1-F
Current (% to the capacity of the main breaker of this product)
MIN
Operating time
MAX
MAX
MIN
4h
2h
1h
30min
20min
14min
10min
6min
4min
2min
1min
30s
20s
10s
5s
2s
1s
0.5s
0.2s
0.1s
0.05s
0.02s
0.01s
100 135 200 300 400 500 600 700 1000 1500 2000 3000 4000
Figure 3-8 Breaker operating characteristics curve
