IMU User Guide revision 3.1 SMC Ship Motion Control www.shipmotion.eu
3.7.2 DEPTH RATED UNIT
RS232 Output Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
1
Black
RS232 – RxD
3
2
White
RS232 – TxD
2
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
RS422 Output Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
3
Red
RS422 – TxD+
3
4
Green
RS422 – TxD-
4
5
Orange
RS422 – RxD-
1
6
Blue
RS422 – RxD+
2
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12to 30Vdc
RS232 Serial Input 1 Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
7
White/Black
RS232 – TxD
2
8
Red/Black
RS232 – RxD
3
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
RS232 Serial Input 2 Connections DB9 Connections
IMU Connector
Cable Colour
IMU Function
DB9 to PC/Converter
9
Green/Black
RS232 – TxD
2
10
Orange/Black
RS232 – RxD
3
11
Blue/Black
Supply Voltage -
5
12
Black/White
Supply Voltage + 12 to 30Vdc
