4.5 ETHERNET
The SMC motion sensor IMU-00x and IMU-10x with hardware version 8.5 or higher is equipped with
a 10/100mbit ethernet communication port. The SMC data output over Ethernet is sent in an 8 bit
per byte binary format. The data can be viewed from the SMC IMU configuration software or other
third-party software suitable to read the ethernet messages.
The configuration of the motion sensor is done using the SMC IMU Configuration Software. Both
serial communication and ethernet communication can be used to do the desired settings.
For a SMC motion sensor outputting data over ethernet the following settings can be done from the
SMC IMU configuration software related the communication.
