SMC Networks JXC73 Series User Manual

- 89 -
No.SFOD-OMT0010-B
(2) Driver alarm
Name of
the
controller
setting
software
(code)
Group
How to
deactivate
Alarms and countermeasures
Step data
value is
wrong
(1-048)
B
Input
RESET
< Details >
The step data or parameter is incorrect for the following
parameter assignable range.
[Settable range]
(1) Pushing force ≥ Trigger level
(2) Pushing force > 0
(3) Speed ≥ Pushing speed ≥ Minimum speed of the
actuator
(4) Pushing speedMaximum pushing speed of the actuator
(5) Pushing force≥Minimum pushing force of actuator
(6) The Basic parameter "Max pushing force"minimum
pushing force of the actuator
(7) The Basic parameter "Max pushing force"  “Trigger
level”.
<Countermeasure>
Modify the step data and basic parameter settings
Caution
Please refer to the actuator manual or the catalogue for
the max/min pushing force/speed for the actuator.
Parameter
value is
wrong
(1-049)
B
Input
RESET
< Details >
The parameter is incorrect for the following parameter
assignable range.
[Settable range]
(1) Stroke (-) < Stroke (+)
(2) Parameter “Max pushing force” < maximum pushing
force of the actuator
<Countermeasure>
Modify the basic parameter settings.
Caution
Please refer to the actuator manual or the catalogue for
the max pushing force for the actuator.
Set stroke
is outside
stroke limit.
(1-052)
B
Input
RESET
< Details >
An alarm is generated when an operation exceeds the basic
parameter "Stroke (+)", "Stroke (-)". (Including JOG operation
after a Return to origin)
<Countermeasure>
Make sure that the basic parameters “Stroke (+)” and “Stroke
(-)” are consistent with the distance of the actuator movement
specified in the step data.
Caution
If the step data operation method is a “relative movement”,
note the location where the operation starts and the
distance moved.
If the location is outside the stroke range when power is
supplied, this alarm will be generated. Move the table to
within the stroke range, and supply power.
