SMC Networks JXC73 Series User Manual

- 90 -
No.SFOD-OMT0010-B
Name of
the
controller
setting
software
(code)
Group
How to
deactivate
Alarms and countermeasures
Return to
ORIG did
not
complete in
the set time.
(1-097)
C
Input
RESET
< Details >
Return to origin was not completed within the set time.
<Countermeasure>
- If the ORIG mode is "0: Pushing Return to origin", the controller
parameter “model” and the actual actuator model may not match.
Check the parameters. Also, the motor shaft may be loose.
Please refer to the actuator operation manual.
- If the ORIG mode is "2, 3: Return to origin with sensor", check
that the sensor mounting and the cable connection of the sensor
are correct.
DRIVE is
ON when
SVRE is
OFF
(1-098)
C
Input
RESET
< Details >
An alarm is generated when a Return to origin instruction is made
when the servo is OFF.
<Countermeasure>
Start the operation when the servo motor is ON (SVRE output is
ON).
