5. External Connectio
ns
An exa
mple of st
andard wiring of the c
ontroller is show
n for each connect
or
.
5.1 PWR:
Power supply
c
onnector
Refer to
6.
CN1: Power sup
ply plug (P
.
23
)
for wiring.
Caution
Do not use an
inrush current limited
type of p
ower supply for t
he controller.
5.2 MOT
:
Motor connector
,
ENC:
Encoder c
onnector
Connect the
controller
and the actuator wit
h the act
uator cable (LE-
CP
-
□
)
5.3 SI:
Serial I/O Connector
(1) Connecti
ng
the t
eaching box
Controller
Actuator ca
ble
MOT
ENC
Actuator
Motor
Controller
PWR
Controller
input power
supply
24VDC
(The Controller po
wer supply (24VDC
) and wires must be prepa
red by
the user
.)
Wire
Conversion cable
Controller
SI
T
eaching
box
(3m cable is prov
ided)
21
